Laboratory tests

Test and check performed by research laboratoires

Analysis of limescale deposit on dry residue (at 180°C) performed by electron microscope.

Water as it is

Calcite: 40% - Aragonite: 60%
CALCITE: rhombohedral Calcium Carbonate
crystal with strong cohesive and adhesive properties.

Water treated with Physico®

Calcite: 0% - Aragonite: 100%
ARAGONITE: needle-like Calcium Carbonate
crystal with weak cohesive and adhesive properties.

Visual inspection of the external condition of
copper heat exchangers after the test conducted by the University of Padua

Depuratori acqua

Heating coil with untreated water
Calcite: 30%
Aragonite: 70%

Heating coil with treated water
Calcite: 0%
Aragonite: 100%

Electron microscope images inside the heat exchanger
after testing by the University of Padua.

Scambiatori acqua


Calcium carbonate crystals 10÷20 μm thick

Scambiatori acqua


Calcium carbonate crystals 0,03 μm thick

Depuratori acqua

Pipe before the installation of Physico®

Pipe after the installation of Physico®

In order to certify the effectiveness of the results, the Physico® anti-limescale water treatment system has been extensively tested and certified by the Universities of Padua and Milan.

The different crystallisation process induced by the treatment leads to a drastic reduction in the strength of cohesion between the crystals, thereby reducing the build-up of limescale.

Results obtained through microbiological tests

Microbiological tests carried out by laboratories certify that Physico® produces a constant and effective bactericidal action which reduces the pathogenic micro-organisms found in water.

Effect of the electromagnetic field on the total bacteria count in well water at 37°C
A: Untreated water
B: Treated water

Effect of the electromagnetic field on faecal coliforms in river water
A: Untreated water
B: Treated water

Effect of the electromagnetic field on the total amount of coliforms
A: Untreated water
B: Treated water

Verification tests for practical application in a boiler service centre




Physico® has obtained certification for the validity of the treatment from major research laboratories. A great achievement for those like us at Tecnoacque, who work for innovation and the environment every day. The certification of the tests performed on Physico’s action against the build-up of limescale, as well as on the wholesomeness of the water, is not only a guarantee for users, but also for designers and installers, because they know they can rely on the excellence of Italian research and on acting ethically and responsibly.
